Little Giant

1/3 HP 1-1/2" F Submersible Sump Pump 115V Diaphragm

1/3 HP 1-1/2" F Submersible Sump Pump 115V Diaphragm

Regular price $215.79
Regular price $215.79 Sale price $215.79
Sale Sold out
Shipping calculated at checkout.

This Little Giant 6-CIA 1/3 HP 1-1/2" F Submersible Sump Pump is a powerful tool that you can rely on. It has a shaft seal made of nitrile with carbon and ceramic faces, which provides increased durability. With an off point from 1 in to 4 in. and an on point from 7 in to 10 in., this submersible sump pump delivers maximum performance when it comes to draining liquids. The epoxy coated cast iron housing keeps the unit free from rust and corrosion, while the diaphragm casing ensures long life for the product. This 1/3 hp sump pump has a max liquid temperature of 140 degrees F and a max temp of 140 degrees F. If you need a dependable submersible sump pump, the Little Giant 6-CIA will not let you down.

Specifications

  • Mfr #: 506158
  • Cord Length: 10 ft
  • Discharge NPT: 1-1/2" F
  • Housing Material: Epoxy Coated Cast Iron
  • HP: 1/3
  • Hz: 50/60 Hz
  • Impeller Material: Nylon
  • Max. Head: 18.0 ft
  • Max. Temp.: 140 Degrees F
  • Motor RPM: 1500
  • Motor Type: Split Phase
  • Shaft Seal: Nitrile with Carbon and Ceramic Faces
  • Voltage: 115V
  • Max. Head - Pumps: 18 ft.
  • Shaft Seal Material - Pumps: Carbon, Ceramic
  • Switch Type - Pumps: Diaphragm
  • Amps - Pumps: 9.00
  • Max. Dia. Solids: 1/8"
  • Cord Length - Pumps: 9 ft.
  • Item - Sump Pumps: Submersible Sump Pump
  • NEC Cord Designation: SJTW
  • Alarm Included: No
  • Off Point: 1 in to 4 in
  • Switch Type: Diaphragm
  • GPM of Water @ 10 Ft. of Head: 29
  • Diameter: 9-1/2"
  • Max. Diameter Solids: 1/8 in
  • Alarm: No
  • Amps: 9 A
  • GPM of Water @ 15 Ft. of Head: 13
  • Max. Liquid Temp.: 140 Degrees F
  • Mechanical Seal: CRB/CMC
  • Pump Body Material: Cast Iron
  • Height: 6"
  • GPM of Water @ 5 Ft. of Head: 46
  • Item: Submersible Sump Pump
  • Pump HP: 1/3
  • Voltage - Pumps: 120VAC
  • Gauge/Conductor: 18/3
  • Base Material: Polypropylene
  • Impeller Material - Pumps: Nylon
  • Manufacturers Warranty Length: 2 yr
  • On Point: 7 in to 10 in
  • Switch Actuation: Diaphragm
  • Body Material: Cast Iron
  • Rated Voltage: 115V AC
  • Switch Electrical Connection: Integral
  • RPM: 1,500 RPM
  • Body Dia.: 9 1/2 in
  • Overall Height: 6 in
  • Flow Rate @ 15 Ft. of Head: 13.0 gpm
  • Flow Rate @ 10 Ft. of Head: 29.0 gpm
  • Discharge Standard: NPT
  • Flow Rate @ 5 Ft. of Head: 46.0 gpm
  • Discharge Gender: Female
  • Duty Cycle: Continuous
  • Discharge Dia.: 1 1/2 in
  • Discharge: 1 1/2 in FNPT
