36 in Whole House Fan Economy Ceiling Truss Shutter / Ceiling Shutter

Whole House Fan Economy Ceiling Truss Shutter / Ceiling Shutter, Fits Fan Dia. 36 in, Shutter Overall Size 38 in L x 36 in W, Shutter Construction Material Extruded Aluminum Frame and G-90 Galvanized Tie Rods, Shutter Opening Required 35-3/4 in x 34 in, Shutter Free Area 7.126 sq ft, Horizontal Shutter Mounting Position, Shutter Mounting Location Ceiling, Length 37 3/4 in, Width 36 in, Frame Depth 1 3/8 in, Open Depth 5 in, Flange Width 1 1/2 in, Mounting Hole Size Prepunched

Specifications:

Promotion Restriction: Not eligible for promotion
Item: Whole House Fan Economy Ceiling Truss Shutter / Ceiling Shutter
Shutter Mounting Position: Horizontal
Shutter Mounting Location: Ceiling
Shutter Construction Material: Extruded Aluminum Frame and G-90 Galvanized Tie Rods
Shutter Free Area: 7.126 sq ft
Shutter Opening Required: 35-3/4 in x 34 in
Shutter Overall Size: 38 in L x 36 in W
Fits Fan Dia.: 36 in
Blade Material: White Painted Aluminum
Max. Velocity: 1500 FPM
Width: 36 in
Number of Panels: 1
Frame Opening A: -
Frame Depth: 1 3/8 in
Length: 37 3/4 in
For Use With: 3C375, 5M156
Frame Opening B: -
Flange Width: 1 1/2 in
Shutter Overall Square: 23"
Shutter Item: Whole House Fan Economy Ceiling Truss Shutter
Mounting Hole Size: Prepunched
Open Depth: 5 in
Length (Straight Wireway): 37 3/4 in
