SQUARE D

Load Center, 6 Spaces, 100 A Amps, 120/240V AC, QO Circuit Breaker Type

Load Center, 6 Spaces, 100 A Amps, 120/240V AC, QO Circuit Breaker Type

Regular price $67.20
Regular price $67.20 Sale price $67.20
Sale Sold out
Shipping calculated at checkout.
Load Center, Number of Spaces 6, Amps 100 A, Voltage 120/240V AC, Circuit Breaker Type QO, Included Enclosure Cover Surface Cover, Main Circuit Breaker or Main Lug Main Lug, Max. No. of Tandem Breakers 6, Phase 1, Series QO, Height 12 9/16 in, Width 8 29/32 in, Depth 3 3/4 in, For Use With Square D QO Circuit Breakers, Bus Material Tin Plated Aluminum, Short Circuit Current Rating 10kA, Enclosure NEMA Rating 1, Cover Attachment Style Screw On, Cover Closure Method Lift-Off

Specifications

  • Mfr #: QO612L100DS
  • Item: Load Center
  • Enclosure NEMA Rating: 1
  • Main Circuit Breaker or Main Lug: Main Lug
  • Number of Spaces: 6
  • Phase: 1
  • Voltage: 120/240V AC
  • Circuit Breaker Type: QO
  • Max. No. of Tandem Breakers: 6
  • Height: 12.56 in
  • Width: 8.91 in
  • Amps: 100 A
  • Short Circuit Current Rating: 10kA
  • Recommended Ground Bar Kit: 1D374
  • Depth: 3 3/4 in
  • Special Features: Green Premium Product, Mercury Free, Toxic Heavy Metal Free
  • Enclosure Material: Steel
  • Recommended Surface Cover: Included
  • Bus Material: Tin Plated Aluminum
  • Standards: RoHS Compliant, UL Listed
  • Series: QO
  • Cover Closure Method: Lift-Off
  • For Use With: Square D QO Circuit Breakers
  • Feed Location: Top/Bottom
  • Cover Attachment Style: Screw On
  • Location: Indoor
  • Enclosure Surface Finish: Enamel
  • Color: Gray
  • Max. Operating Temp.: 104 Degrees F
  • Min. Operating Temp.: 23 Degrees F
  • Included Enclosure Cover: Surface Cover
View full details
