Description
Condensate, Reservoir Size - Pumps Small, Voltage - Pumps 115V AC, 1/30 hp HP - Pumps, 93 W Watts, Reservoir Capacity - Pumps 1/3 gal, 3/8 in Barb Discharge Size - Pumps, Max. Head - Pumps 21 ft, Max. Temp - Pumps 140 Degrees F, 1.5 A Amps, Height 6 1/2 in, Length 10 13/64 in, Width 4 51/64 in, Float Material Polypropylene, Cord Length 6 ft, Shaft Material Stainless Steel, Standards cCSAus
Specifications
- Mfr #: 554550
- Condensate Pumps - Type: Condensate
- Item: Condensate Removal Pump
- Reservoir Size - Pumps: Small
- Voltage: 115
- HP - Pumps: 1/30 hp
- Voltage - Pumps: 115V AC
- Reservoir Capacity - Pumps: 1/3 gal
- Discharge Size - Pumps: 3/8 in Barb
- Max. Temp - Pumps: 140 Degrees F
- GPH of Water @ 12 Ft. of Head: 54
- GPH of Water @ 30 Ft. of Head: -
- Amps: 1.5 A
- HP: 1/30
- Includes: 20 ft of 3/8 in Vinyl Tubing, 6 ft Power Cord, Rubber Feet, Safety Switch Assembly, Tank Mounting Bracket, Thermal Overload Protector, Turn Check Valve
- Shaft Material: Stainless Steel
- GPH of Water @ 20 Ft. of Head: 10
- Width: 4 51/64 in
- GPH of Water @ 40 Ft. of Head: -
- Reservoir Capacity: 1/3 gal.
- GPH of Water @ 9 Ft. of Head: 64
- Length: 10 13/64 in
- Standards: cCSAus
- GPH of Water @ 15 Ft. of Head: 42
- Cord Length: 6 ft
- Max. Head - Pumps: 21 ft
- Pump Type: Vertical
- GPH of Water @ 5 Ft. of Head: 75
- Max. Temp.: 140 Degrees F
- GPH of Water @ 1 Ft. of Head: 84
- Shut-Off: 21 ft.
- Watts: 93 W
- Float Material: Polypropylene
- Discharge: 3/8" Barb
- Height: 6 1/2 in
- Length (Straight Wireway): 10 13/64 in
